HICLOVER TS-30D PLC Incinerator (Former YD-30 PLC): Intelligent Small-Scale Waste Incineration Solution
The HICLOVER TS-30D PLC incinerator, previously known as YD-30 PLC, is a compact, fully automatic waste incineration system designed for facilities that require stable high-temperature destruction, operator safety, and fuel-efficient operation. With a nominal burn rate of 30 kg per hour, the TS-30D PLC is optimized for medical, laboratory, small industrial, and institutional waste disposal where compliance, reliability, and controlled emissions are critical.
Built on HICLOVER’s long-established incinerator design philosophy, the TS-30D PLC combines traditional refractory engineering with modern PLC automation, ensuring consistent performance under continuous operation.
Designed for Controlled and Safe Waste Destruction
The TS-30D PLC adopts a dual-chamber high-temperature configuration with adjustable high-temperature retention (HTR). The system ensures complete oxidation of waste and flue gases while minimizing operator exposure and environmental risks.
-
Average burn rate: 30 kg/hour
-
Feed mode: Manual feeding with intelligent operator protection
-
Continuous operation logic supported by PLC automation
-
Automatic burner ignition and shutdown
The intelligent sensor system enables continuous feeding logic while preventing unsafe access during operation, reinforcing worker protection standards.
Dual-Chamber High-Temperature Combustion System
Primary Combustion Chamber
-
Volume: 330 L
-
Internal dimensions: 75 × 75 × 60 cm
-
Operating temperature: 800 ℃ – 1000 ℃
-
Hot face refractory:
-
Thickness ≥ 115 mm
-
≥ 65 % Al₂O₃
-
1750 ℃ grade
-
-
Cold face insulation: High-grade refractory ceramic fiber
Secondary Combustion Chamber
-
Volume: 180 L
-
Operating temperature: 1000 ℃ – 1300 ℃
-
Gas residence time: ≥ 2.0 seconds
-
Mix combustion chamber ensures uniform gas turbulence and complete oxidation
This configuration is suitable for pathological waste, infectious materials, pharmaceutical residues, and small-volume hazardous waste.
PLC Automatic Control and Intelligent Monitoring
The TS-30D PLC is equipped with a PLC automatic control system with LCD interface, enabling precise control, monitoring, and diagnostics.
Key control features include:
-
Real-time temperature monitoring with corundum probe tube (rated up to 1400 ℃)
-
Progress display bar and time visualization
-
Programmable time settings
-
System self-testing mode
-
Automatic false alarm detection
-
Automatic protection operator (APO) logic
-
Automatic cooling cycle after shutdown
The PLC system reduces dependence on operator experience and improves long-term operational stability.
Fuel Efficiency and Burner Configuration
The TS-30D PLC is designed with intelligent fuel-saving logic, optimizing burner operation based on chamber temperature feedback.
-
Burner type: Italy brand
-
Fuel options:
-
Diesel oil (standard)
-
Natural gas (optional configuration)
-
-
Diesel consumption: ~10 kg/hour
-
Burner operation: Fully automatic ON/OFF
This approach balances combustion stability, fuel economy, and equipment longevity.
Integrated Flue Gas Treatment Options
To meet diverse environmental requirements, the TS-30D PLC includes a dry smoke filter chamber as standard.
-
Dry scrubber: Included
-
Wet scrubber: Optional (site-specific emission control)
-
Chimney height: 5 meters
-
Chimney material: Stainless Steel 304
This modular approach allows adaptation to local emission standards without over-engineering.
Mechanical Structure and Feeding Options
-
Feeding door options:
-
Side / front loading: 55 × 50 cm
-
Top loading (optional): 75 × 75 cm
-
-
External dimensions (main body): 175 × 120 × 140 cm
-
Gross weight: ~3500 kg
-
Sealing material: Refractory ceramic fiber
-
Exterior paint: 250 ℃ high-temperature resistant coating
An upgrade to containerized mobile type is available for remote or temporary installations.
Electrical and Utility Requirements
-
Voltage: 220 V
-
Installed power: 0.7 kW
-
Oil tank capacity: 200 L
-
Oil tank stand: Included
-
Liquid level display: Standard
Low electrical demand makes the TS-30D PLC suitable for areas with limited infrastructure.
Certifications and Compliance
The TS-30D PLC is manufactured under certified quality and compliance systems:
-
CE certification:
-
2006/42/EC
-
2014/30/EU
-
-
ISO certification: ISO 9001:2015
-
High-Tech Enterprise Certification: Yes
These certifications support international procurement, institutional buyers, and regulated markets.
Typical Application Scenarios
The HICLOVER TS-30D PLC incinerator is well suited for:
-
Hospitals and clinics
-
Laboratories and research centers
-
Veterinary facilities
-
Quarantine stations
-
Small industrial waste treatment points
-
Remote or decentralized waste management sites
Its balance of traditional refractory durability and forward-looking PLC automation makes it a dependable long-term asset.
Conclusion
The HICLOVER TS-30D PLC incinerator represents a refined evolution of the YD-30 PLC platform, offering stable high-temperature combustion, intelligent control, and flexible emission treatment in a compact footprint. It is a practical solution for facilities seeking reliable small-scale incineration with modern safety and efficiency standards.
For technical inquiries or configuration options, visit www.hiclover.com or contact sales@hiclover.com.
